Hang 470 PLC Ring Binder & Lever arch Assembly Line

High-performance automatic production line for ring binders
Brand: Hang
Model: 470 PLC – FANUC Controlled

This fully automatic line is designed for efficient production of ring binders according to customer specifications. The machine is equipped with multiple processing stations and a Fanuc PLC control with touchscreen interface.

Main Components:

Sheet feeder (Saug-Anleger)
Creasing station
Gripping hole punching unit (Griffloch-Ösmaschine)
Double riveting station
Operator control panel (Fanuc QuickPanel View)
Mechanic feeding unit
Single riveting station
Folding station
Technical Specifications

PLC Control: FANUC with memory for up to 1000 programs and modem for remote support

Setup time: Approx. 2-3 minutes

Material Range:

Cover height: 120 – 400 mm
Cover width: 300 – 820 mm

Material thickness: Min. 1 mm – Max. 3.5 mm
Rivet spacing: 90 – 300 mm

Machine Condition

✔ In excellent working condition
✔ Touch panel with program counter, total counter and production statistics
✔ Fanuc QuickPanel View display
✔ Ready for immediate production
✔ Available for inspection in our warehouse

✅ Production Counter Information (Machine Usage)

Day Counter: 250,895 cycles
Total Counter: 9,495,162 cycles
Product Counter: 1,336,482 units
Operating Time: 12,838 hours
